MULTIPURPOSE WATERPROOFING MEMBRANE

This product is a 1 mm self-adhesive membrane composed of SBS modified bitumen. This membrane is perfect to waterproof various repair and maintenance works around the house, cottage, or farm.


Benefits

  • Low temperature flexibility
  • Resistant to outdoor temperature changes
  • Available in white or aluminum
  • Reflects heat
  • Can be covered with acrylic paint
  • Effective and hard-wearing
  • Clean and easy installation
  • No special tools required
  • UV resistant

Tests and certifications

ISO-9001
ISO-14001

Function

Waterproofing

Product Roles

  • Cap Sheet Membranes
  • Waterproofing Membranes

Building Component

Roofs

Technology

SBS modified bitumen

Types of Slope

Outside steep slope

Substrates

  • Plywood
  • OSB
  • Metal

Surface

  • Metallized HDPE system
  • White HDPE system

Underface

Silicone release film

Application

Self-adhesive

Thickness

1 mm (40 mils)

Storage instructions

Rolls should be stored upright. Tape side up. Can withstand freezing but must be reactivated to at least 10 ° C (50 °F) before installation.

Minimum application temperature

10 °C (50 °F)

Tools required

  • Knife
  • Tape measure
  • Smoothing roller
  • Roller

Surface Preparation

The substrate must be clean, dry, and free of dust, grease or other contaminants.

Restrictions

It is not recommended to use a product containing bitumen directly on softwood boards or flexible polyvinyl chloride. For installation over EPDM or TPO membrane, please contact RESISTO technical service.

previous-photo-0
MULTIPURPOSE WATERPROOFING MEMBRANE

Products

Product code

Width

Length

Gross area

Net area

Weight

Weight per skid

Color

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66524

Width

10 cm (4 in)

Length

5 m (16 ft)

Gross area

0.50 m² (5.3 ft²)

Net area

0.2 m² (3 pi²)

Weight

0.52 kg (1.15 lb)

Weight per skid

324 kg (715 lb)

Color

WHITE

White

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66522

Width

30 cm (12 in)

Length

5 m (16 ft)

Gross area

1.50 m² (16.0 ft²)

Net area

1.2 m² (13 pi²)

Weight

1.57 kg (3.46 lb)

Weight per skid

324 kg (715 lb)

Color

WHITE

White

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66529

Width

23 cm (9 in)

Length

5 m (16 ft)

Gross area

1.15 m² (12.0 ft²)

Net area

0.9 m² (9 pi²)

Weight

1.36 kg (3 lb)

Weight per skid

324 kg (715 lb)

Color

WHITE

White

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66526

Width

15 cm (6 in)

Length

5 m (16 ft)

Gross area

0.75 m² (8.0 ft²)

Net area

0.5 m² (5 pi²)

Weight

0.78 kg (1.72 lb)

Weight per skid

324 kg (715 lb)

Color

WHITE

White

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66578

Width

46 cm (18 in)

Length

5 m (16 ft)

Gross area

2.30 m² (24.0 ft²)

Net area

2.0 m² (21 pi²)

Weight

2.35 kg (5.18 lb)

Weight per skid

324 kg (715 lb)

Color

ALUMINIUM

Alu

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66528

Width

46 cm (18 in)

Length

5 m (16 ft)

Gross area

2.30 m² (24.0 ft²)

Net area

2.0 m² (21 pi²)

Weight

2.35 kg (5.18 lb)

Weight per skid

324 kg (715 lb)

Color

WHITE

White

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66520

Width

91 cm (36 in)

Length

5 m (16 ft)

Gross area

4.55 m² (48.0 ft²)

Net area

4.3 m² (45 pi²)

Weight

5.3 kg (11.7 lb)

Weight per skid

324 kg (715 lb)

Color

WHITE

White

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66572

Width

30 cm (12 in)

Length

5 m (16 ft)

Gross area

1.50 m² (16.0 ft²)

Net area

1.2 m² (13 pi²)

Weight

1.57 kg (3.46 lb)

Weight per skid

324 kg (715 lb)

Color

ALUMINIUM

Alu

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66579

Width

23 cm (9 in)

Length

5 m (16 ft)

Gross area

1.15 m² (12.0 ft²)

Net area

0.9 m² (9 pi²)

Weight

1.36 kg (3 lb)

Weight per skid

324 kg (715 lb)

Color

ALUMINIUM

Alu

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66576

Width

15 cm (6 in)

Length

5 m (16 ft)

Gross area

0.75 m² (8.0 ft²)

Net area

0.5 m² (5 pi²)

Weight

0.78 kg (1.72 lb)

Weight per skid

324 kg (715 lb)

Color

ALUMINIUM

Alu

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66574

Width

10 cm (4 in)

Length

5 m (16 ft)

Gross area

0.50 m² (5.3 ft²)

Net area

0.2 m² (3 pi²)

Weight

0.52 kg (1.15 lb)

Weight per skid

324 kg (715 lb)

Color

ALUMINIUM

Alu

MULTIPURPOSE WATERPROOFING MEMBRANE

Product code

66570

Width

91 cm (36 in)

Length

5 m (16 ft)

Gross area

4.55 m² (48.0 ft²)

Net area

4.3 m² (45 pi²)

Weight

5.3 kg (11.7 lb)

Weight per skid

324 kg (715 lb)

Color

ALUMINIUM

Alu

Products

Barcodes

Product code

Units per box

Units per skid

Boxes per skid

Weight per skid

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66524 8

Product code

66524

Units per box

9

Units per skid

864

Boxes per skid

96

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66522 4

Product code

66522

Units per box

3

Units per skid

288

Boxes per skid

96

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66529 3

Product code

66529

Units per box

4

Units per skid

360

Boxes per skid

90

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66526 2

Product code

66526

Units per box

6

Units per skid

576

Boxes per skid

96

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66578 1

Product code

66578

Units per box

2

Units per skid

180

Boxes per skid

90

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66528 6

Product code

66528

Units per box

2

Units per skid

180

Boxes per skid

90

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66520 0

Product code

66520

Units per box

1

Units per skid

54

Boxes per skid

54

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66572 9

Product code

66572

Units per box

3

Units per skid

288

Boxes per skid

96

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66579 8

Product code

66579

Units per box

4

Units per skid

360

Boxes per skid

90

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66576 7

Product code

66576

Units per box

6

Units per skid

576

Boxes per skid

96

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66574 3

Product code

66574

Units per box

9

Units per skid

864

Boxes per skid

96

Weight per skid

324 kg (715 lb)

MULTIPURPOSE WATERPROOFING MEMBRANE

Barcodes

6 23680 66570 5

Product code

66570

Units per box

1

Units per skid

54

Boxes per skid

54

Weight per skid

324 kg (715 lb)
